CONICAL SPRING BALANCED SEALS
Series TMS-003 are a cost effective version of a balanced seal. They feature the same rugged and reliable construction as the unbalanced spring seals in TMS-001. These seals are primarily used in the chemical sector and in water pumps.
Seal Characteristics
• Single Seal• Unbalanced
• Conical Spring
• Dependent on direction of rotation
Applications
• Water pumps• Submersible pump
• Sewage pump
Performance Range
• Shaft Diameter : 10...100mm• Pressure : 20 bar (max)
• Temperature : -20...180OC
• Velocity : 15 m/sec
Materials
• Seal Faces : Carbon, Ceramic, SiC, Tung. Carbide• Metal Parts : SS304, SS316
• O-rings : Elastomers, TTV
